ESP8 passenger platform
Gotion 51.46 kWh LFP
3450 mm wheelbase
AC/DC GB/T reference
Confirm final seating drawing
A passenger minibus order needs more than a seat-count label. This KAMA ESP8 configuration summary helps buyers check the battery nameplate, body dimensions, seating drawing and charging interface against the final vehicle before shipment.
| Item | Reference configuration |
|---|---|
| Model | ESP8 passenger minibus |
| Battery | Gotion lithium iron phosphate, 51.46 kWh |
| Drive position | Left-hand drive in this reference specification; other steering arrangements require separate confirmation |
| Overall dimensions | 5265 × 1870 × 2060 mm |
| Wheelbase | 3450 mm |
| Motor rated / peak power | 35 / 70 kW |
| Maximum speed | 95 km/h reference specification |
| Reference range | 300 km, CLTC reference cycle; actual route range varies |
| Charging | AC and DC GB/T in this reference configuration; connector and charger compatibility must be checked |
| Seating | 15/16 or 18/19-seat layout families in the source; final total including driver and approved seating drawing must be confirmed |
| Equipment listed | ABS, power steering, front and rear air conditioning, power windows and central locking |
Match the VIN and model plate to the agreed vehicle specification.
Record the battery manufacturer and capacity from the relevant vehicle evidence.
Count total seats, including the driver, against the approved layout. Check belts and access paths.
Check the supplied inlet and charging equipment against the local installation.
Confirm the equipment list and document any deviations before shipment.
Staff and campus shuttle routes can be assessed where local registration and charging arrangements are suitable. CLTC is a reference test cycle, not a promise of daily route range. Allow for load, terrain, traffic, climate, battery condition and charging reserves.
The source lists several seating layout families. Confirm the final total, including the driver, and the approved order drawing. The website description does not establish destination registration approval.
No. It is the CLTC reference stated in the local specification. Route distance depends on actual operating conditions and reserve requirements.
No. The reference specifies AC and DC GB/T. Confirm the inlet, charger output, protocol and local installation before placing an order.
Send the destination, steering side, total seats, daily route distance, terrain, passenger and luggage requirements, expected quantity and charging details. Contact KAMA for a version-specific technical review.
